XFP 10G 1550nm 80km Transceiver

Parameter

Symbol

Min

Max

Unit

Storage Temperature

TST

-40

+85

℃

Case Operating Temperature

TIP

0

+70

℃

Supply Voltage 1

VCC3

-0.5

+4.0

V

Supply Voltage 2

VCC5

-0.5

+6.0

V

Parameter

Symbol

Min

Typ

Max

Unit

Note

Supply Voltage 1

Vcc5

4.75

5.25

V

Supply Voltage 2

Vcc3

3.13

3.45

V

Supply Current – Vcc5 supply

Icc5

250

mA

Supply Current – Vcc3 supply

Icc3

500

mA

Module total power

P

3.5

W

Transmitter

Input differential impedance

Rin

100

Ω

1

Differential data input swing

Vin,pp

150

820

mV

Transmit Disable Voltage

VD

2.0

Vcc

V

Transmit Enable Voltage

VEN

GND

GND+ 0.8

V

Transmit Disable Assert Time

T_off

100

ms

Tx Enable Assert Time

T_on

100

ms

Receiver

Differential data output swing

Vout,pp

300

500

850

mV

Data output rise time

tr

35

ps

2

Data output fall time

tf

35

ps

2

LOS Fault

VLOS fault

Vcc – 0.5

VccHOST

V

3

LOS Normal

VLOS norm

GND

GND+0.5

V

3

Power Supply Rejection

PSR

See Note 4 below

4

Parameter

Symbol

Min

Typ

Max

Unit

Ref.

Transmitter

Operating Date Rate

BR

9.95

11.3

Gb/s

Bit Error Rate

BER

10-12

Maximum Launch Power

PMAX

1

+5

dBm

1

Optical Wavelength

λ

1530

1550

1565

nm

Optical Extinction Ratio

ER

8.2

dB

Spectral Width

Δλ

1

nm

Sidemode Suppression ratio

SSRmin

30

dB

Rise/Fall Time (20%~80%)

Tr/Tf

35

ps

Average Launch power of OFF Transmitter

POFF

-30

dBm

Tx Jitter

Txj

Compliant with each standard requirement

Optical Eye Mask

IEEE802.3ae

2

Receiver

Operating Date Rate

BR

9.95

11.3

Gb/s

Receiver Sensitivity

Sen

-24

dBm

2

Maximum Input Power

PMAX

-7

dBm

2

Optical Center Wavelength

λC

1260

1600

nm

Receiver Reflectance

Rrx

-27

dB

LOS De-Assert

LOSD

-24

dBm

LOS Assert

LOSA

-34

dBm

LOS Hysteresis

LOSH

0.5

5

dB
