241006 High-speed optical module package Describes QSFP+/QSFP28/QSFP56/QSFP112

(Fiberwdm All rights Reserved)

Keywords: 40G optical module, 100G optical module, 200G optical module, 400G optical module

QSFP+,QSFP28,QSFP56,QSFP112

First of all, understand the QSFP package, QSFP is Quad Small Form-Factor Pluggable, QSFP refers to the four-channel small hot-swappable SFP interface, the difference between QSFP packaged optical module and SFP optical module is to replace the single-channel SFP optical module with a high-density optical module. Therefore, compared with the SFP optical module, the QSFP optical module has a higher bandwidth.

The 40G QSFP+ optical module and 100G QSFP28 optical module developed on the basis of QSFP package have a wide range of applications in high-density data center network deployment

40G QSFP+ optical module is based on 4 channels 10G pluggable optical module, is a technical solution of 4X10G

The 100G QSFP28 optical module is also a 4-channel pluggable optical module, which is a 4X25G technical solution |

The 200G QSFP56 optical module is an upgraded version of the 40G QSFP+ and 100G QSFP28 optical modules. The QSFP56 represents a transfer rate of 4x 50Gb/s to 56Gb/s in a QSFP package size

The 400G QSFP112 optical module is 4X100G transmission rate

QSFP+/QSFP28/QSFP56/QSFP112 are developed on the basis of QSFP and are based on 4-channel pluggable optical modules

QSFP+, 40G, is 4X10G NRZ

QSFP28, 100G, is 4X25G NRZ

QSFP56, 200G, 4X50G PAM4

QSFP112,400G, 4X100G PAM4
