Features： Wide bandwidth                          Low insertion loss                        High channel isolation       Exceptional reliability and stability

Triple Play Integration, 16-channel FWDM Low Loss, High Isolation, Wide Temperature Stability Supports Multi-Services for CATV/PON/XGS-PON 1U Rack-Mountable, High-Density Integration

Efficient Transmission: It supports 4 channels of 100G signals with dual - fiber transmission, offering a large capacity and a transmission distance of up to 10 km. Scalable: Equipped with an expansion port, it can increase network capacity without the need for new optical fibers. Easy Installation: The plug - in LGX box is designed to fit into a 2 - slot 1U rack. Excellent Performance: With a wavelength range of 1270 - 1330nm, it has multiple good - performing indicators and can adapt to a wide temperature range. Wide Application: It is suitable for multiple industries, especially in areas with scarce optical fiber resources. Customization - friendly: Customized designs are available. You can contact us via email for more details.

Single-fiber bidirectional transmission：Supports 2-channel Drop/Add services over a single fiber, optimizing scarce fiber resources. Low insertion loss：≤1.5dB for wave-to-line, ≤2.4dB for west-east/east-west transmission, ensuring efficient signal propagation. High isolation：≥30dB adjacent channel isolation and ≥45dB non-adjacent isolation, minimizing crosstalk. Wide temperature tolerance：Operates/stores between -40°C to 85°C, suitable for extreme environmental conditions. Modular deployment：FMU plug-in module compatible with 2-slot 1U rack or LGX BOX for flexible installation.

Single-fiber Bidirectional Transmission: Enables 4-channel (8-wavelength) bidirectional transmission over one fiber, supporting 8 types of services. Dual-direction Wavelength Separation: Independent A/B side wavelength ranges (1470–1530nm/1550–1610nm) eliminate interference. Passive Design: No power supply required, ensuring low power consumption and easy maintenance. Flexible Deployment: Plug-in LGX box with 2-slot 1U rack for space-saving and 便捷 installation. High Reliability: Low insertion loss (≤2.4dB), high return loss (≥45dB), and wide operating temperature range (-40°C to 85°C). Multi-service Adaptability: Supports 1G/10G Ethernet, SDH/SONET, etc., suitable for broadcast, finance, cloud, and other industries. Intelligent Monitoring: MON port enables online link monitoring without disrupting traffic.

  IL<3.5dB , 100GHZ DWDM MUX DEMUX Multiplexing of 16 Channels over a Dark Fiber Network Fully Compatible with All ITU-T 1G/10G/25G/40G/100G DWDM Optics Passive devices, No Power No Cooling Required Support Metro, Regional and Long Haul DWDM Networks

6ch /12ch CWDM are used in 4G/5G fronthaul system Features Low Insertion Loss High Isolation Low PDL Compact Design Good channel-to-channel uniformity Wide Operating Wavelength: 1270nm to 1620nm Wide Operating Temperature: -20 to 70°C

Single-line dual-access - product features:   Easy to install and concealed： Single-line dual-access is a passive device with a low failure rate;  Small in size and can be used in a variety of ways fast installation in complex environment, strong concealment. Low insertion loss：The insertion loss of single-line dual-access devices is < 1.6dB, and the line margin is within the range after going online.

  IL<2.4dB , 100GHZ DWDM MUX DEMUX Multiplexing of 8 Channels over a Dark Fiber Network Fully Compatible with All ITU-T 1G/10G/25G/40G/100G DWDM Optics Passive devices, No Power No Cooling Required Support Metro, Regional and Long Haul DWDM Networks

IL<6.0dB , 100GHZ DWDM AAWG Technology Fully Compatible with All ITU-T 1G/10G/25G/40G/100G DWDM Optics Passive devices, No Power No Cooling Required Support Metro, Regional and Long Haul DWDM Networks

IL

IL
