241012 200G high speed optical module and AOC/DAC products

(Fiberwdm All rights Reserved)

Keywords: 200G optical module, QSFP56, QSFP-DD, AOC, DAC

There are two mainstream technical directions for 200G optical modules, one is the QSFP-DD package, and the other is the QSFP56 package

QSFP56 package, is the extension of QSFP system package, is a 4-channel structure; QSFP56 200G optical module is 4X50G to achieve 200G transmission, taking PAM4 modulation technology.

QSFP-DD package, where the "DD" refers to double density, that is, the number of optical module channels in the QSFP-DD package is 8, QSFP-DD 200G optical module, that is, 8X25G, using NRZ modulation technology.

The QSFP-DD optical module is backward compatible with QSFP package optical modules such as 40G QSFP+, 100G QSFP28, and 200G QSFP56.

QSFP56 Package 200G optical module Specifications:

QSFP56 200G SR4

QSFP56 200G DR4

QSFP56 200G FR4

QSFP56 200G LR4

QSFP56 200G ER4

QSFP-DD package 200G optical module Specifications:

QSFP-DD 200G SR8

QSFP-DD 200G PSM8

QSFP-DD 200G LR8

QSFP-DD 200G ER8

200G QSFP56 and QSFP-DD product comparison table

Fiberwdm 200G optical module/AOC/DAC

FiberWDM provides 200G optical modules, AOC and DAC products, The optical modules include but are not limited to 200G QSFP56 SR4, 200G QSFP56 FR4, 200G QSFP56 LR4, 200G QSFP-DD SR8, 200G QSFP-DD PSM8, 200G QSFP-DD LR8 and 200G QSFP56 AOC, 200G QSFP-DD AOC, 200G QSFP56 DAC and 200G QSFP-DD DAC. It provides a more flexible and adaptable interconnection solution for data centers.
