100G CFP2 ER4 Dual Rate 40km Module

Part No.

Data Rate

Laser

Fiber Type

Distance

Optical Interface

Temp

DDMI

CFP2-100G-ER4

103.1~111.8Gbps

LWDM

SMF

40km

LC

0~70C

Y

Parameter

Symbol

Min.

Typical

Max.

Unit

Notes

Operating Case Temperature

TC

0

-

+70

°C

Power Supply Voltage

VCC

3.13

3.3

3.47

V

Maximum Power Dissipation

PD

-

-

14

W

Aggregate Bit Rate

BRAVE

-

103.125

111.8

Gb/s

Lane Bit Rate

BRLANE

-

25.78

27.95

Gb/s

Transmission Distance

TD

-

40

km

Over SMF

Transmitter

Parameter

Symbol

Min.

Typical

Max.

Unit

Notes

Center Wavelength Lane 0

λ0

1294.53

1295.56

1296.59

nm

Center Wavelength Lane 1

λ1

1299.02

1300.05

1301.09

nm

Center Wavelength Lane 2

λ2

1303.54

1304.58

1305.63

nm

Center Wavelength Lane 3

λ3

1308.09

1309.14

1310.19

nm

Total Launch Power, 100GE

PALL

-

-

8.9

dBm

1

Average Launch Power per Lane, 100GE

PTX_LANE

-2.9

-

2.9

dBm

1

OMA per Lane, 100GE

OMA

0.1

-

4.5

dBm

Difference in launch power between lanes

PTX_DELTA_LANE

-

-

3.6

dB

Total Launch Output Power, OTU4

PALL

-

-

8.9

dBm

1

Average Launch Power per Lane, OTU4

PTX_LANE

-2.7

-

2.9

dBm

1

Average Output Power (Laser Turn off)

POUT-OFF

-

-

-30

dBm

Side Mode Suppression Ratio

SMSR

30

-

-

dB

Extinction Ratio, 100GE/ OTU4

ER

8

-

-

dB

Optical Eye Mask, 100GE

Compliant with IEEE 802.3ba

2

Optical Eye Mask, OTU4

Compliant with ITU-T G.959.1

2

Receiver

Parameter

Symbol

Min.

Typical

Max.

Unit

Notes

Center Wavelength Lane 0

λ0

1294.53

1295.56

1296.59

nm

Center Wavelength Lane 1

λ1

1299.02

1300.05

1301.09

nm

Center Wavelength Lane 2

λ2

1303.54

1304.58

1305.63

nm

Center Wavelength Lane 3

λ3

1308.09

1309.14

1310.19

nm

Average Rx Power per Lane, 100GE

PRX _LANE

-20.9

4.5

dBm

OMA Sensitivity per Lane, 100GE

POMA_LANE

-

-

-20.4

dBm

3

Average Rx Power per Lane, OTU4

PRX_AVE_LANE

-20.7

4.5

dBm

Sensitivity per Lane, OTU4

PRX_AVE_LANE

-

-

-22.2

dBm

4

Receiver Damage

Pdamage

5.5

-

-

dBm

Transmitter (Module Input)

Parameter

Symbol

Min.

Typical

Max.

Unit

Notes

Differential Data Input Amplitude

VIN,P-P

85

-

900

mVpp

Differential Termination Mismatch

-

-

10

%

Tx_Disable

Normal Operation

VIL

-0.3

-

0.8

V

Laser Disable

VIH

2.0

-

VCC+0.3

V

Receiver (Module Output)

Parameter

Symbol

Min.

Typical

Max.

Unit

Notes

Differential Data Output Amplitude

VOUT,P-P

200

-

900

mVpp

Differential Termination Mismatch（1MHZ）

-

-

10

%

Output Rise/Fall Time, 20%~80%

TR

12

-

-

ps

Rx_LOS

Normal Operation

VOL

-

-

0.2

V

Lose Signal

VOH

VCC-0.2

-

-

V

Parameter

Range

Accuracy

Unit

Calibration

Temperature

-5 to 70

±3

ºC

Internal

Voltage

0 to VCC

±3%

V

Internal

Tx Bias Current Per Lane

0 to 100

±10%

mA

Internal

Tx Output Power Per Lane

-2.9 to 2.9

±3

dB

Internal

Rx Power (Each Lane)

-20.9 to 4.5

±3

dB

Internal
