100G CFP2 LR4 single Rate 10km Module

Part No.

Data Rate

Laser

Fiber Type

Distance

Optical Interface

Temp

DDMI

CFP2-100G-LR4

103.1~111.8Gbps

LWDM

SMF

10km

LC

-5~70C

Y

Parameter

Symbol

Min.

Typical

Max.

Unit

Notes

Operating Case Temperature

TC

-5

-

+70

°C

Power Supply Voltage

VCC

3.13

3.3

3.47

V

Power Supply Current

ICC

1.8

Maximum Power Dissipation

PD

-

-

6

W

Aggregate Bit Rate

BRAVE

-

103.125

-

Gb/s

Lane Bit Rate

BRLANE

-

25.78

-

Gb/s

Transmission Distance

TD

-

10

km

Over SMF

Transmitter

Parameter

Symbol

Min.

Typical

Max.

Unit

Notes

Center Wavelength Lane 0

λ0

1294.53

1295.56

1296.59

nm

Center Wavelength Lane 1

λ1

1299.02

1300.05

1301.09

nm

Center Wavelength Lane 2

λ2

1303.54

1304.58

1305.63

nm

Center Wavelength Lane 3

λ3

1308.09

1309.14

1310.19

nm

Total Launch Power, 100GE

PALL

-

-

10.5

dBm

1

Average Launch Power per Lane, 100GE

PTX_LANE

-4.3

-

4.5

dBm

1

OMA per Lane, 100GE

OMA

-1.3

-

4.5

dBm

1

OMA–TDP per Lane, 100GE

OMA_TDP

-2.3

-

-

dBm

Difference in launch power between lanes

PTX_DELTA_LANE

-

-

3.6

dB

Average Output Power (Laser Turn off)

P0UT-OFF

-

-

-30

dBm

Side Mode Suppression Ratio

SMSR

30

-

-

dB

Extinction Ratio, 100GE

ER

4

-

-

dB

Transmitter and Dispersion Penalty

TDP

-

-

2.2

dB

2

Optical Return Loss Tolerance

ORLT

-

-

20

dB

Optical Eye Mask, 100GE

Compliant with IEEE 802.3bm

2

Receiver

Parameter

Symbol

Min.

Typical

Max.

Unit

Notes

Center Wavelength Lane 0

λ0

1294.53

1295.56

1296.59

nm

Center Wavelength Lane 1

λ1

1299.02

1300.05

1301.09

nm

Center Wavelength Lane 2

λ2

1303.54

1304.58

1305.63

nm

Center Wavelength Lane 3

λ3

1308.09

1309.14

1310.19

nm

Average Rx Power per Lane, 100GE

PRX _LANE

-10.6

4.5

dBm

3

OMA Sensitivity per Lane, 100GE

POMA_LANE

-

-

-8.6

dBm

3

Receiver Overload

PIN-OL

4.5

-

-

dBm

Reflectance

Ref

-

-

-26

dB

LOS Assert per lane

LOSA

-20

-

-

dBm

LOS De-assert

LOSD

-

-

-12

dBm

LOS Hysteresis

LOSH

0.5

4

dB

Transmitter (Module Input)

Parameter

Symbol

Min.

Typical

Max.

Unit

Notes

Differential Data Input Amplitude

VIN,P-P

85

-

900

mVpp

Differential Termination Mismatch

-

-

10

%

Tx_Disable

Normal Operation

VIL

-0.3

-

0.8

V

Laser Disable

VIH

2.0

-

VCC+0.3

V

Receiver (Module Output)

Parameter

Symbol

Min.

Typical

Max.

Unit

Notes

Differential Data Output Amplitude

VOUT,P-P

200

-

900

mVpp

Differential Termination Mismatch（1MHZ）

-

-

10

%

Output Rise/Fall Time, 20%~80%

TR

12

-

-

ps

Rx_LOS

Normal Operation

VOL

-

-

0.2

V

Lose Signal

VOH

VCC-0.2

-

-

V

Parameter

Range

Accuracy

Unit

Calibration

Temperature

0 to 70

±3

ºC

Internal

Voltage

0 to VCC

0.1

V

Internal

Tx Bias Current Per Lane

0 to 100

10%

mA

Internal

Tx Output Power Per Lane

-4.3 to 4.5

±3

dBm

Internal

Rx Power (Each Lane)

-10.6to 4.5

±3

dBm

Internal
