2-Optical 8-Electric Ethernet Gigabit Industrial Switch FW108GS-2F
2-Optical 8-Electric Ethernet Gigabit Industrial Switch FW108GS-2F

2-Optical 8-Electric Ethernet Gigabit Industrial Switch FW108GS-2F



FW108GS-2F is an industrial full gigabit management Ethernet switch, 8* 10/100/1000Mbps RJ45 port+2 * gigabit SFP port+1 * Console port.



Inquire now Download
  • Product Detail

10 Ports Gigabit 2-Optical 8-Electric Ethernet Gigabit Industrial Switch
FW108GS-2F




Product Features


FW108GS-2F is an industrial full gigabit management Ethernet switch, 8* 10/100/1000Mbps RJ45 port+2 * gigabit SFP port+1 * Console port.




Product Details


Product Model


FW108GS-2F


Network Interface


  • 8 10/100/1000M RJ45 ports
  • 2 Gigabit SFP ports
  • 1 Console port



Performance Specifications



  • MAC address table: 8k
  • Backplane bandwidth: 20Gbps
  • Packet forwarding rate: 14.9Mpps
  • Forwarding mode: store and forward



Power Support



  • Voltage input: 48-56V DC
  • Input mode: plug-in 5-core 5.08mm spacing terminal block


LED Indicator


  • Power indicator: P1, P2
  • System indicator: SYS
  • Alarm indicator: ALM
  • Ethernet port indicator: Link&Act1-8
  • Optical port indicator: Link&Act F1-F2


Environmental Specifications


  • Operating temperature: - 40-75℃
  • Storage humidity: - 40-85℃
  • Relative humidity: 5% - 95% (non condensing)



Network Protocol



  • IEEE802.3、IEEE802.3i、IEEE802.3u、IEEE802.3ab、
  • IEEE802.3z、IEEE802.3ad、IEEE802.3x、IEEE802.3af/at、
  • IEEE802.3p、IEEE802.3q、IEEE802.3w、IEEE802.3d、IEEE802.3s


Management


  • 2L+


Antistatic


  • ±8kV(contact),±15kV (air)


Size（W*D*H）


  • 163*46.5*110mm






Technical Parameter


VLAN



  • Support IEEE 802.1Q VLAN, MAC VLAN, IP VLAN, Voice VLAN. Users can flexibly divide VLAN according to different requirements
  • Support 1:1 and N: 1 VLAN Mapping



Multicast Management



  • Support IGMP v1/v2/v3 Snooping, MLD v1/v2 Snooping
  • Support quick exit mechanism
  • Support multicast VLAN
  • Support multicast filtering, message statistics, and unknown multicast discarding



Security Management



  • Based on user hierarchical management and password protection
  • Support port based access control protocol IEEE 802.1x, IP address, MAC address to restrict user access
  • Support ARP protection, IP source protection, DoS protection
  • Support 802.1X authentication, Radius, Tacacs+
  • Support port security and port isolation



Network Management



  • Support ARP protection, IP source protection, DoS protection, etc
  • Support WEB network management (HTTP, HTTPS, SSL V3, TSL V1).
  • Support CLI (Telnet, SSH V1/V2, local serial port)
  • Support SNMP V1/V2/V3, compatible with public MIBs and TP-LINK private MIBS
  • Support CPU monitoring and memory monitoring
  • Support system logs and graded warnings
  • Support Ping, Tracert detection and cable detection







Application Collocation
